PP Polypropylene Melt Blown Filter Cartridge With Orange Surface

Unique Orange Peel Surface
High Dirt-Holding Capacity
Effective Contaminant Removal
Wide Application Range
Low Pressure Drop

Description

PP Polypropylene Melt Blown Filter Cartridge With Orange Surface

Product Overview

The PP Melt Blown Filter Cartridge with Orange Surface is a high-performance filtration solution featuring a unique, wrinkled surface that resembles orange peel. This distinctive design increases the surface area, improving filtration efficiency. Like the standard PP melt-blown filter cartridges, it is made by fusing polypropylene resin without the use of chemical adhesives. The random bonding of fibers creates a 3D microporous structure, resulting in three distinct layers: fine fibers on the surface, coarse fibers in the middle, and a deep filtration zone. The wrinkled surface ensures a larger filtration area while maintaining the same excellent contaminant removal capabilities, long service life, and low-pressure drop.

Key Features:

✅ Unique Orange Peel Surface: The wrinkled surface increases filtration area for improved efficiency.

✅ High Filtration Performance: Available in micron ratings from 1 to 200 for a wide range of applications.

✅ Efficient Contaminant Removal: Effectively removes suspended solids, particulates, and rust.

✅ Long Service Life: High dirt-holding capacity extends filter lifespan and reduces maintenance.

✅ Low Pressure Drop: Ensures efficient filtration with minimal pressure loss, maximizing system performance.

Specifications:

Product Name	PP Melt Blown Filter Cartridge with Orange Surface
Length	10"	20"	30"	40"
Flow(t/h)	0.5	1	1.5	2
Area(㎡)	0.5	1	1.5	2
Diameter(Standard)	OD(63mm), ID(30mm)
Diameter(Jumbo)	OD(115mm), ID(30mm)
Material	PP Polypropylene
Micron rating(μm)	1, 5, 10, 25, 50, 75, 100, 150, 200
