Nylon Liquid Filter Bag
- High strength and durability
- Excellent solvent resistance
- Suitable for high-temperature applications up to 149°C
Nylon Liquid Filter Bag
Product Overview
AAL Filter Nylon mesh Filter bags are designed to handle higher solid loading and are suitable for applications using bag housing or open filtration systems. With Nylon Filter bags, you can count on a quality product every time. Highly controlled manufacturing procedures ensure consistent quality with no contamination. The unique bag designs provide added strength and avoid the risk of bypass. AAL Filter bags will fit all industry-standard bag housings.
Key Features:
✅ Useful and long life time
✅ High performance in efficiency
✅ Greater reliability of operations
✅ Better utilization of machines and equipment
✅ More positive seal between filter bag change and installation
Specifications:
Filter Media | Nylon mesh Felt, polyester Felt,polypropylene |
Max. Operating Temperature | Polypropylene: 200-220° F(93-104°C) Polyester: 275-325° F(135-162°C) Nylon: 275-300° F(135-149°C) |
Micron Rating | Polypropylene: 0.5,1,3,5,10, 25, 50.100, 200 Polyester: 0.5,1,3,5, 10, 25,50, 75.100, 200 Nylon: 25,50,100,150,200,300, 400,500,600,800,1200,1250 |
collar Ring | Polypropylene ring Polyester ring galvanized steel ring Stainless steel ring Rope |
Bag Construction | Sewn or Welded |
Remark | The length of filter bags can be customized lf your filter bag is different from our filter bag size, please send us your drawingIsize and the material which you need, we also produce the nonstandard filter bag. |
Filter Media | Polypropylene Felt, Polyester Felt, Nomex Felt |
Bag Dimensions | Size 1: 7"×17"inch |
Size 2: 7"× 32"inch | |
Size 3: 4"× 9"inch | |
Size 4: 4"× 15"inch | |
Filtration Rating | 1, 5, 10, 25, 50, 75, 100, 150, 200, 300μm |
Ring Style | Galvanized Steel O-Ring, Plastic Ring, S.S. O-Ring |
Seam | Welded, Sewing, Welded top & Sewing Bottom, Sewing top & Welded Bottom |
Tech Support
Filter Media | Acids | Bases | Solvents | oxidizing Agents | Temperature (℃) |
Polyester(PE) | Good | Good | Excellent | Limited | 150-170 |
Polypropylene(PP) | Excellent | Excellent | Good | Excellent | 90-110 |
Nylon(NMO) | Fair | Good | Excellent | Fair | 150-170 |
PTFE | Excellent | Excellent | Excellent | Excellent | 250-300 |
Our team is available for troubleshooting, technical assistance, and to help you select the right filtration solutions for your applications.
Applications
✅ Automotive Industry:
· Used in the filtration of lubricants, coolants, and hydraulic fluids to ensure the smooth operation of vehicles and machinery.
· Commonly applied in automotive manufacturing and maintenance facilities.
✅ Chemical Processing:
· Utilized in the filtration of aggressive chemicals and solvents to remove particulates and ensure process efficiency.
· Applied in chemical manufacturing and processing plants.
✅ Water Treatment:
· Employed in the filtration of industrial wastewater and process water to remove contaminants and ensure compliance with environmental regulations.
· Used in industrial water treatment facilities.
✅ Food and Beverage Industry:
· Used in the filtration of beverages and food products to ensure clarity and remove particulates.
· Commonly found in food processing and beverage production facilities.
✅ Pharmaceuticals:
· Applied in the filtration of pharmaceutical solutions and APIs to ensure sterility and purity.
· Used in drug manufacturing and biotech facilities.
